Project Size: Institute of 360 Student & 30 Faculty, Plot Area of 5.56 Acres & Floor Area of 2,50,000 Sqft.
AT BADAMI BAGH CANTONMENT, SRINAGAR, JAMMU & KASHMIR Project Size: Plot Area of 4 Acres & Floor Area of 33,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Srinagar Zone Project Cost: approx 9.0 Crore. Consultant: Aakar Consultant & Infrastructure Developers Pvt Ltd Profile: Architecture Consultancy, Design & Planning based on Admin Approval & Board Proceeding Incorporation of client’s feedback. Preparat ion of complete Working, Detail, Services & Structural drawings. Co-ordination between Services, Structural Consultants. Schedule of Finishes, Bill of Quantity, Specification & Tender Document preparation. Specialist Design Provision of Pool Water Heating & Filtration System, Lighting of Sports Arena for Day Night Gaming Facility.
AT 407 AIR FORCE BASE, COIMBATORE, TAMILNADU Project Size: Plot Area of 4 Acres & Floor Area of 1,10,000Sqft. Client Name: Military Engineer Service, Chief Engineer Bangalore Zone Project Cost: Rs. 27.00 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram & Scale of Accommodation for Armed Force Hospital-2003, Admin Approval and Board Proceedings, Presentation & Approval from E6 Section & User (CO-6AF Hospital, Coimbatore) and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010
Complete Master Planning Work of All Building Types and Garages. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per Guidelines of Dept. Complete Architectural Work, Structural Work, Electrical & Plumbing Services work of Admin Block, Educational Building, and Officers Mess & SM Barracks and all other Bldgs. Working Drawings, Detailed Designs, SoF and BoQ for Lump-sum Tender Job as per requirement of MES.
AT BIKANER MILITARY STATION, RAJASTHAN Comprehensive Design Consultancy including Master Planning, Services Incorporation, & Co-ordination of entire land and Detailed Architecture & Engineering Consultancy for Administrative, Educational, Officers Mess, Armory Building, Officers Accommodation and multiple type S/M Barracks.
Project Size: Plot Area of 2.0 Acres & Builtup Area of 1,04,000 Sqft, 70 Nos. 2 & 3 BHK Apartments Project Cost: Rs. 14.00 Crore, Client Name: Esquire Infra Height Pvt Ltd Profile: Principal Architect involved in Design Development, All Approvals, Working, Tendering, Coordination and Supervision of the Project.
Complete Consultancy Work for 2 Storied Large Industrial Hall for repair & maintenance of INS Vikramaditya with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per SPT Method for 20M depth & foundation assessment. Complete Architectural Work, Structural Designing Work, and Electrical & Plumbing Services work of Main Hall (15 M High & Ancillary Buildings (AC Plant Room, Guard House etc).
Project Size: Institute of 360 Student & 30 Faculty, Plot Area of 5.56 Acres & Floor Area of 2,50,000 Sqft. Client Name: Indian Army (Bengal HQ), Kolkata. Profile: Principal Architect worked from conceptual design, area program, green building concept 3D view and complete design. Consultant: Aakar Consultant & Infrastructure Developers
Proposal of 70 Classes, 10 Labs with provision of future expansion of 70 Classes, 14 Labs. Complete Consultancy Work including Architectural, Structure Detailed Designs, Working Drawings, SoF, 3-D Walk-thru and BoQ for Lump-sum Tender Job. Complete Building Services Design (HVAC/Mechanical, Electrical and Plumbing & Fire Fighting), Structural Work of Admin Block, Educational Building, and Laboratory Block & Multipurpose Hall Block with adherence of clauses of NBC-2005. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user [Commandant of Bombay Sappers, Principal of School] for their input.
AT COMMAND HOSPITAL, KOLKATA Project Size: Plot Area of 2 Acres & Floor Area of 90,000Sqft. Client Name: Military Engineer Service, Chief Engineer Kolkata Zone. Profile: Principal Architect with Hospital Design & Planning, Structure & Services incl MGPS System, worked on Conceptual Design & Planning based on Line Diagram & Approval from All Departments & and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010.
Project Size: Plot Area of 10 Acres & Floor Area of 70,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Udhampur Zone Project Cost: Rs. 21.0 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram, Admin Approval and Board Proceedings, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BIKANER AND BATHINDA, RAJASTHAN Project Size: Plot Area of 6 Acres & Floor Area of 30,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Bathinda Zone. Project Cost: Rs. 13.26 Crore (as per Admin Approval) Profile: Principal Design & Engineering Consultant, worked on Conceptual Design & Planning based all Cinematography Standards & Statutory Guidelines, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BADAMI BAGH CANTONMENT, SRINAGAR, JAMMU & KASHMIR Project Size: Plot Area of 4 Acres & Floor Area of 33,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Srinagar Zone Project Cost: approx 9.0 Crore. Consultant: Aakar Consultant & Infrastructure Developers Pvt Ltd Profile: Architecture Consultancy, Design & Planning based on Admin Approval & Board Proceeding Incorporation of client’s feedback. Preparat ion of complete Working, Detail, Services & Structural drawings. Co-ordination between Services, Structural Consultants. Schedule of Finishes, Bill of Quantity, Specification & Tender Document preparation. Specialist Design Provision of Pool Water Heating & Filtration System, Lighting of Sports Arena for Day Night Gaming Facility.
AT 407 AIR FORCE BASE, COIMBATORE, TAMILNADU Project Size: Plot Area of 4 Acres & Floor Area of 1,10,000Sqft. Client Name: Military Engineer Service, Chief Engineer Bangalore Zone Project Cost: Rs. 27.00 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram & Scale of Accommodation for Armed Force Hospital-2003, Admin Approval and Board Proceedings, Presentation & Approval from E6 Section & User (CO-6AF Hospital, Coimbatore) and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010
Complete Master Planning Work of All Building Types and Garages. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per Guidelines of Dept. Complete Architectural Work, Structural Work, Electrical & Plumbing Services work of Admin Block, Educational Building, and Officers Mess & SM Barracks and all other Bldgs. Working Drawings, Detailed Designs, SoF and BoQ for Lump-sum Tender Job as per requirement of MES.
AT BIKANER MILITARY STATION, RAJASTHAN Comprehensive Design Consultancy including Master Planning, Services Incorporation, & Co-ordination of entire land and Detailed Architecture & Engineering Consultancy for Administrative, Educational, Officers Mess, Armory Building, Officers Accommodation and multiple type S/M Barracks.
Project Size: Plot Area of 2.0 Acres & Builtup Area of 1,04,000 Sqft, 70 Nos. 2 & 3 BHK Apartments Project Cost: Rs. 14.00 Crore, Client Name: Esquire Infra Height Pvt Ltd Profile: Principal Architect involved in Design Development, All Approvals, Working, Tendering, Coordination and Supervision of the Project.
Complete Consultancy Work for 2 Storied Large Industrial Hall for repair & maintenance of INS Vikramaditya with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per SPT Method for 20M depth & foundation assessment. Complete Architectural Work, Structural Designing Work, and Electrical & Plumbing Services work of Main Hall (15 M High & Ancillary Buildings (AC Plant Room, Guard House etc).
Project Size: Institute of 360 Student & 30 Faculty, Plot Area of 5.56 Acres & Floor Area of 2,50,000 Sqft. Client Name: Indian Army (Bengal HQ), Kolkata. Profile: Principal Architect worked from conceptual design, area program, green building concept 3D view and complete design. Consultant: Aakar Consultant & Infrastructure Developers
Proposal of 70 Classes, 10 Labs with provision of future expansion of 70 Classes, 14 Labs. Complete Consultancy Work including Architectural, Structure Detailed Designs, Working Drawings, SoF, 3-D Walk-thru and BoQ for Lump-sum Tender Job. Complete Building Services Design (HVAC/Mechanical, Electrical and Plumbing & Fire Fighting), Structural Work of Admin Block, Educational Building, and Laboratory Block & Multipurpose Hall Block with adherence of clauses of NBC-2005. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user [Commandant of Bombay Sappers, Principal of School] for their input.
AT COMMAND HOSPITAL, KOLKATA Project Size: Plot Area of 2 Acres & Floor Area of 90,000Sqft. Client Name: Military Engineer Service, Chief Engineer Kolkata Zone. Profile: Principal Architect with Hospital Design & Planning, Structure & Services incl MGPS System, worked on Conceptual Design & Planning based on Line Diagram & Approval from All Departments & and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010.
Project Size: Plot Area of 10 Acres & Floor Area of 70,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Udhampur Zone Project Cost: Rs. 21.0 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram, Admin Approval and Board Proceedings, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BIKANER AND BATHINDA, RAJASTHAN Project Size: Plot Area of 6 Acres & Floor Area of 30,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Bathinda Zone. Project Cost: Rs. 13.26 Crore (as per Admin Approval) Profile: Principal Design & Engineering Consultant, worked on Conceptual Design & Planning based all Cinematography Standards & Statutory Guidelines, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BADAMI BAGH CANTONMENT, SRINAGAR, JAMMU & KASHMIR Project Size: Plot Area of 4 Acres & Floor Area of 33,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Srinagar Zone Project Cost: approx 9.0 Crore. Consultant: Aakar Consultant & Infrastructure Developers Pvt Ltd Profile: Architecture Consultancy, Design & Planning based on Admin Approval & Board Proceeding Incorporation of client’s feedback. Preparat ion of complete Working, Detail, Services & Structural drawings. Co-ordination between Services, Structural Consultants. Schedule of Finishes, Bill of Quantity, Specification & Tender Document preparation. Specialist Design Provision of Pool Water Heating & Filtration System, Lighting of Sports Arena for Day Night Gaming Facility.
AT 407 AIR FORCE BASE, COIMBATORE, TAMILNADU Project Size: Plot Area of 4 Acres & Floor Area of 1,10,000Sqft. Client Name: Military Engineer Service, Chief Engineer Bangalore Zone Project Cost: Rs. 27.00 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram & Scale of Accommodation for Armed Force Hospital-2003, Admin Approval and Board Proceedings, Presentation & Approval from E6 Section & User (CO-6AF Hospital, Coimbatore) and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010
Complete Master Planning Work of All Building Types and Garages. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per Guidelines of Dept. Complete Architectural Work, Structural Work, Electrical & Plumbing Services work of Admin Block, Educational Building, and Officers Mess & SM Barracks and all other Bldgs. Working Drawings, Detailed Designs, SoF and BoQ for Lump-sum Tender Job as per requirement of MES.
AT BIKANER MILITARY STATION, RAJASTHAN Comprehensive Design Consultancy including Master Planning, Services Incorporation, & Co-ordination of entire land and Detailed Architecture & Engineering Consultancy for Administrative, Educational, Officers Mess, Armory Building, Officers Accommodation and multiple type S/M Barracks.
Project Size: Plot Area of 2.0 Acres & Builtup Area of 1,04,000 Sqft, 70 Nos. 2 & 3 BHK Apartments Project Cost: Rs. 14.00 Crore, Client Name: Esquire Infra Height Pvt Ltd Profile: Principal Architect involved in Design Development, All Approvals, Working, Tendering, Coordination and Supervision of the Project.
Complete Consultancy Work for 2 Storied Large Industrial Hall for repair & maintenance of INS Vikramaditya with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per SPT Method for 20M depth & foundation assessment. Complete Architectural Work, Structural Designing Work, and Electrical & Plumbing Services work of Main Hall (15 M High & Ancillary Buildings (AC Plant Room, Guard House etc).
Project Size: Institute of 360 Student & 30 Faculty, Plot Area of 5.56 Acres & Floor Area of 2,50,000 Sqft. Client Name: Indian Army (Bengal HQ), Kolkata. Profile: Principal Architect worked from conceptual design, area program, green building concept 3D view and complete design. Consultant: Aakar Consultant & Infrastructure Developers
Proposal of 70 Classes, 10 Labs with provision of future expansion of 70 Classes, 14 Labs. Complete Consultancy Work including Architectural, Structure Detailed Designs, Working Drawings, SoF, 3-D Walk-thru and BoQ for Lump-sum Tender Job. Complete Building Services Design (HVAC/Mechanical, Electrical and Plumbing & Fire Fighting), Structural Work of Admin Block, Educational Building, and Laboratory Block & Multipurpose Hall Block with adherence of clauses of NBC-2005. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user [Commandant of Bombay Sappers, Principal of School] for their input.
AT COMMAND HOSPITAL, KOLKATA Project Size: Plot Area of 2 Acres & Floor Area of 90,000Sqft. Client Name: Military Engineer Service, Chief Engineer Kolkata Zone. Profile: Principal Architect with Hospital Design & Planning, Structure & Services incl MGPS System, worked on Conceptual Design & Planning based on Line Diagram & Approval from All Departments & and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010.
Project Size: Plot Area of 10 Acres & Floor Area of 70,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Udhampur Zone Project Cost: Rs. 21.0 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram, Admin Approval and Board Proceedings, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BIKANER AND BATHINDA, RAJASTHAN Project Size: Plot Area of 6 Acres & Floor Area of 30,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Bathinda Zone. Project Cost: Rs. 13.26 Crore (as per Admin Approval) Profile: Principal Design & Engineering Consultant, worked on Conceptual Design & Planning based all Cinematography Standards & Statutory Guidelines, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BADAMI BAGH CANTONMENT, SRINAGAR, JAMMU & KASHMIR Project Size: Plot Area of 4 Acres & Floor Area of 33,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Srinagar Zone Project Cost: approx 9.0 Crore. Consultant: Aakar Consultant & Infrastructure Developers Pvt Ltd Profile: Architecture Consultancy, Design & Planning based on Admin Approval & Board Proceeding Incorporation of client’s feedback. Preparat ion of complete Working, Detail, Services & Structural drawings. Co-ordination between Services, Structural Consultants. Schedule of Finishes, Bill of Quantity, Specification & Tender Document preparation. Specialist Design Provision of Pool Water Heating & Filtration System, Lighting of Sports Arena for Day Night Gaming Facility.
AT 407 AIR FORCE BASE, COIMBATORE, TAMILNADU Project Size: Plot Area of 4 Acres & Floor Area of 1,10,000Sqft. Client Name: Military Engineer Service, Chief Engineer Bangalore Zone Project Cost: Rs. 27.00 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram & Scale of Accommodation for Armed Force Hospital-2003, Admin Approval and Board Proceedings, Presentation & Approval from E6 Section & User (CO-6AF Hospital, Coimbatore) and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010
Complete Master Planning Work of All Building Types and Garages. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per Guidelines of Dept. Complete Architectural Work, Structural Work, Electrical & Plumbing Services work of Admin Block, Educational Building, and Officers Mess & SM Barracks and all other Bldgs. Working Drawings, Detailed Designs, SoF and BoQ for Lump-sum Tender Job as per requirement of MES.
AT BIKANER MILITARY STATION, RAJASTHAN Comprehensive Design Consultancy including Master Planning, Services Incorporation, & Co-ordination of entire land and Detailed Architecture & Engineering Consultancy for Administrative, Educational, Officers Mess, Armory Building, Officers Accommodation and multiple type S/M Barracks.
Project Size: Plot Area of 2.0 Acres & Builtup Area of 1,04,000 Sqft, 70 Nos. 2 & 3 BHK Apartments Project Cost: Rs. 14.00 Crore, Client Name: Esquire Infra Height Pvt Ltd Profile: Principal Architect involved in Design Development, All Approvals, Working, Tendering, Coordination and Supervision of the Project.
Complete Consultancy Work for 2 Storied Large Industrial Hall for repair & maintenance of INS Vikramaditya with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per SPT Method for 20M depth & foundation assessment. Complete Architectural Work, Structural Designing Work, and Electrical & Plumbing Services work of Main Hall (15 M High & Ancillary Buildings (AC Plant Room, Guard House etc).
Project Size: Institute of 360 Student & 30 Faculty, Plot Area of 5.56 Acres & Floor Area of 2,50,000 Sqft. Client Name: Indian Army (Bengal HQ), Kolkata. Profile: Principal Architect worked from conceptual design, area program, green building concept 3D view and complete design. Consultant: Aakar Consultant & Infrastructure Developers
Proposal of 70 Classes, 10 Labs with provision of future expansion of 70 Classes, 14 Labs. Complete Consultancy Work including Architectural, Structure Detailed Designs, Working Drawings, SoF, 3-D Walk-thru and BoQ for Lump-sum Tender Job. Complete Building Services Design (HVAC/Mechanical, Electrical and Plumbing & Fire Fighting), Structural Work of Admin Block, Educational Building, and Laboratory Block & Multipurpose Hall Block with adherence of clauses of NBC-2005. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user [Commandant of Bombay Sappers, Principal of School] for their input.
AT COMMAND HOSPITAL, KOLKATA Project Size: Plot Area of 2 Acres & Floor Area of 90,000Sqft. Client Name: Military Engineer Service, Chief Engineer Kolkata Zone. Profile: Principal Architect with Hospital Design & Planning, Structure & Services incl MGPS System, worked on Conceptual Design & Planning based on Line Diagram & Approval from All Departments & and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010.
Project Size: Plot Area of 10 Acres & Floor Area of 70,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Udhampur Zone Project Cost: Rs. 21.0 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram, Admin Approval and Board Proceedings, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BIKANER AND BATHINDA, RAJASTHAN Project Size: Plot Area of 6 Acres & Floor Area of 30,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Bathinda Zone. Project Cost: Rs. 13.26 Crore (as per Admin Approval) Profile: Principal Design & Engineering Consultant, worked on Conceptual Design & Planning based all Cinematography Standards & Statutory Guidelines, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BADAMI BAGH CANTONMENT, SRINAGAR, JAMMU & KASHMIR Project Size: Plot Area of 4 Acres & Floor Area of 33,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Srinagar Zone Project Cost: approx 9.0 Crore. Consultant: Aakar Consultant & Infrastructure Developers Pvt Ltd Profile: Architecture Consultancy, Design & Planning based on Admin Approval & Board Proceeding Incorporation of client’s feedback. Preparat ion of complete Working, Detail, Services & Structural drawings. Co-ordination between Services, Structural Consultants. Schedule of Finishes, Bill of Quantity, Specification & Tender Document preparation. Specialist Design Provision of Pool Water Heating & Filtration System, Lighting of Sports Arena for Day Night Gaming Facility.
AT 407 AIR FORCE BASE, COIMBATORE, TAMILNADU Project Size: Plot Area of 4 Acres & Floor Area of 1,10,000Sqft. Client Name: Military Engineer Service, Chief Engineer Bangalore Zone Project Cost: Rs. 27.00 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram & Scale of Accommodation for Armed Force Hospital-2003, Admin Approval and Board Proceedings, Presentation & Approval from E6 Section & User (CO-6AF Hospital, Coimbatore) and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010
Complete Master Planning Work of All Building Types and Garages. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per Guidelines of Dept. Complete Architectural Work, Structural Work, Electrical & Plumbing Services work of Admin Block, Educational Building, and Officers Mess & SM Barracks and all other Bldgs. Working Drawings, Detailed Designs, SoF and BoQ for Lump-sum Tender Job as per requirement of MES.
AT BIKANER MILITARY STATION, RAJASTHAN Comprehensive Design Consultancy including Master Planning, Services Incorporation, & Co-ordination of entire land and Detailed Architecture & Engineering Consultancy for Administrative, Educational, Officers Mess, Armory Building, Officers Accommodation and multiple type S/M Barracks.
Project Size: Plot Area of 2.0 Acres & Builtup Area of 1,04,000 Sqft, 70 Nos. 2 & 3 BHK Apartments Project Cost: Rs. 14.00 Crore, Client Name: Esquire Infra Height Pvt Ltd Profile: Principal Architect involved in Design Development, All Approvals, Working, Tendering, Coordination and Supervision of the Project.
Complete Consultancy Work for 2 Storied Large Industrial Hall for repair & maintenance of INS Vikramaditya with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per SPT Method for 20M depth & foundation assessment. Complete Architectural Work, Structural Designing Work, and Electrical & Plumbing Services work of Main Hall (15 M High & Ancillary Buildings (AC Plant Room, Guard House etc).
Project Size: Institute of 360 Student & 30 Faculty, Plot Area of 5.56 Acres & Floor Area of 2,50,000 Sqft. Client Name: Indian Army (Bengal HQ), Kolkata. Profile: Principal Architect worked from conceptual design, area program, green building concept 3D view and complete design. Consultant: Aakar Consultant & Infrastructure Developers
Proposal of 70 Classes, 10 Labs with provision of future expansion of 70 Classes, 14 Labs. Complete Consultancy Work including Architectural, Structure Detailed Designs, Working Drawings, SoF, 3-D Walk-thru and BoQ for Lump-sum Tender Job. Complete Building Services Design (HVAC/Mechanical, Electrical and Plumbing & Fire Fighting), Structural Work of Admin Block, Educational Building, and Laboratory Block & Multipurpose Hall Block with adherence of clauses of NBC-2005. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user [Commandant of Bombay Sappers, Principal of School] for their input.
AT COMMAND HOSPITAL, KOLKATA Project Size: Plot Area of 2 Acres & Floor Area of 90,000Sqft. Client Name: Military Engineer Service, Chief Engineer Kolkata Zone. Profile: Principal Architect with Hospital Design & Planning, Structure & Services incl MGPS System, worked on Conceptual Design & Planning based on Line Diagram & Approval from All Departments & and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010.
Project Size: Plot Area of 10 Acres & Floor Area of 70,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Udhampur Zone Project Cost: Rs. 21.0 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram, Admin Approval and Board Proceedings, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BIKANER AND BATHINDA, RAJASTHAN Project Size: Plot Area of 6 Acres & Floor Area of 30,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Bathinda Zone. Project Cost: Rs. 13.26 Crore (as per Admin Approval) Profile: Principal Design & Engineering Consultant, worked on Conceptual Design & Planning based all Cinematography Standards & Statutory Guidelines, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BADAMI BAGH CANTONMENT, SRINAGAR, JAMMU & KASHMIR Project Size: Plot Area of 4 Acres & Floor Area of 33,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Srinagar Zone Project Cost: approx 9.0 Crore. Consultant: Aakar Consultant & Infrastructure Developers Pvt Ltd Profile: Architecture Consultancy, Design & Planning based on Admin Approval & Board Proceeding Incorporation of client’s feedback. Preparat ion of complete Working, Detail, Services & Structural drawings. Co-ordination between Services, Structural Consultants. Schedule of Finishes, Bill of Quantity, Specification & Tender Document preparation. Specialist Design Provision of Pool Water Heating & Filtration System, Lighting of Sports Arena for Day Night Gaming Facility.
AT 407 AIR FORCE BASE, COIMBATORE, TAMILNADU Project Size: Plot Area of 4 Acres & Floor Area of 1,10,000Sqft. Client Name: Military Engineer Service, Chief Engineer Bangalore Zone Project Cost: Rs. 27.00 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram & Scale of Accommodation for Armed Force Hospital-2003, Admin Approval and Board Proceedings, Presentation & Approval from E6 Section & User (CO-6AF Hospital, Coimbatore) and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010
Complete Master Planning Work of All Building Types and Garages. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per Guidelines of Dept. Complete Architectural Work, Structural Work, Electrical & Plumbing Services work of Admin Block, Educational Building, and Officers Mess & SM Barracks and all other Bldgs. Working Drawings, Detailed Designs, SoF and BoQ for Lump-sum Tender Job as per requirement of MES.
AT BIKANER MILITARY STATION, RAJASTHAN Comprehensive Design Consultancy including Master Planning, Services Incorporation, & Co-ordination of entire land and Detailed Architecture & Engineering Consultancy for Administrative, Educational, Officers Mess, Armory Building, Officers Accommodation and multiple type S/M Barracks.
Project Size: Plot Area of 2.0 Acres & Builtup Area of 1,04,000 Sqft, 70 Nos. 2 & 3 BHK Apartments Project Cost: Rs. 14.00 Crore, Client Name: Esquire Infra Height Pvt Ltd Profile: Principal Architect involved in Design Development, All Approvals, Working, Tendering, Coordination and Supervision of the Project.
Complete Consultancy Work for 2 Storied Large Industrial Hall for repair & maintenance of INS Vikramaditya with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per SPT Method for 20M depth & foundation assessment. Complete Architectural Work, Structural Designing Work, and Electrical & Plumbing Services work of Main Hall (15 M High & Ancillary Buildings (AC Plant Room, Guard House etc).
Project Size: Institute of 360 Student & 30 Faculty, Plot Area of 5.56 Acres & Floor Area of 2,50,000 Sqft. Client Name: Indian Army (Bengal HQ), Kolkata. Profile: Principal Architect worked from conceptual design, area program, green building concept 3D view and complete design. Consultant: Aakar Consultant & Infrastructure Developers
Proposal of 70 Classes, 10 Labs with provision of future expansion of 70 Classes, 14 Labs. Complete Consultancy Work including Architectural, Structure Detailed Designs, Working Drawings, SoF, 3-D Walk-thru and BoQ for Lump-sum Tender Job. Complete Building Services Design (HVAC/Mechanical, Electrical and Plumbing & Fire Fighting), Structural Work of Admin Block, Educational Building, and Laboratory Block & Multipurpose Hall Block with adherence of clauses of NBC-2005. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user [Commandant of Bombay Sappers, Principal of School] for their input.
AT COMMAND HOSPITAL, KOLKATA Project Size: Plot Area of 2 Acres & Floor Area of 90,000Sqft. Client Name: Military Engineer Service, Chief Engineer Kolkata Zone. Profile: Principal Architect with Hospital Design & Planning, Structure & Services incl MGPS System, worked on Conceptual Design & Planning based on Line Diagram & Approval from All Departments & and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010.
Project Size: Plot Area of 10 Acres & Floor Area of 70,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Udhampur Zone Project Cost: Rs. 21.0 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram, Admin Approval and Board Proceedings, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BIKANER AND BATHINDA, RAJASTHAN Project Size: Plot Area of 6 Acres & Floor Area of 30,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Bathinda Zone. Project Cost: Rs. 13.26 Crore (as per Admin Approval) Profile: Principal Design & Engineering Consultant, worked on Conceptual Design & Planning based all Cinematography Standards & Statutory Guidelines, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BADAMI BAGH CANTONMENT, SRINAGAR, JAMMU & KASHMIR Project Size: Plot Area of 4 Acres & Floor Area of 33,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Srinagar Zone Project Cost: approx 9.0 Crore. Consultant: Aakar Consultant & Infrastructure Developers Pvt Ltd Profile: Architecture Consultancy, Design & Planning based on Admin Approval & Board Proceeding Incorporation of client’s feedback. Preparat ion of complete Working, Detail, Services & Structural drawings. Co-ordination between Services, Structural Consultants. Schedule of Finishes, Bill of Quantity, Specification & Tender Document preparation. Specialist Design Provision of Pool Water Heating & Filtration System, Lighting of Sports Arena for Day Night Gaming Facility.
AT 407 AIR FORCE BASE, COIMBATORE, TAMILNADU Project Size: Plot Area of 4 Acres & Floor Area of 1,10,000Sqft. Client Name: Military Engineer Service, Chief Engineer Bangalore Zone Project Cost: Rs. 27.00 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram & Scale of Accommodation for Armed Force Hospital-2003, Admin Approval and Board Proceedings, Presentation & Approval from E6 Section & User (CO-6AF Hospital, Coimbatore) and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010
Complete Master Planning Work of All Building Types and Garages. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per Guidelines of Dept. Complete Architectural Work, Structural Work, Electrical & Plumbing Services work of Admin Block, Educational Building, and Officers Mess & SM Barracks and all other Bldgs. Working Drawings, Detailed Designs, SoF and BoQ for Lump-sum Tender Job as per requirement of MES.
AT BIKANER MILITARY STATION, RAJASTHAN Comprehensive Design Consultancy including Master Planning, Services Incorporation, & Co-ordination of entire land and Detailed Architecture & Engineering Consultancy for Administrative, Educational, Officers Mess, Armory Building, Officers Accommodation and multiple type S/M Barracks.
Project Size: Plot Area of 2.0 Acres & Builtup Area of 1,04,000 Sqft, 70 Nos. 2 & 3 BHK Apartments Project Cost: Rs. 14.00 Crore, Client Name: Esquire Infra Height Pvt Ltd Profile: Principal Architect involved in Design Development, All Approvals, Working, Tendering, Coordination and Supervision of the Project.
Complete Consultancy Work for 2 Storied Large Industrial Hall for repair & maintenance of INS Vikramaditya with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per SPT Method for 20M depth & foundation assessment. Complete Architectural Work, Structural Designing Work, and Electrical & Plumbing Services work of Main Hall (15 M High & Ancillary Buildings (AC Plant Room, Guard House etc).
Project Size: Institute of 360 Student & 30 Faculty, Plot Area of 5.56 Acres & Floor Area of 2,50,000 Sqft. Client Name: Indian Army (Bengal HQ), Kolkata. Profile: Principal Architect worked from conceptual design, area program, green building concept 3D view and complete design. Consultant: Aakar Consultant & Infrastructure Developers
Proposal of 70 Classes, 10 Labs with provision of future expansion of 70 Classes, 14 Labs. Complete Consultancy Work including Architectural, Structure Detailed Designs, Working Drawings, SoF, 3-D Walk-thru and BoQ for Lump-sum Tender Job. Complete Building Services Design (HVAC/Mechanical, Electrical and Plumbing & Fire Fighting), Structural Work of Admin Block, Educational Building, and Laboratory Block & Multipurpose Hall Block with adherence of clauses of NBC-2005. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user [Commandant of Bombay Sappers, Principal of School] for their input.
AT COMMAND HOSPITAL, KOLKATA Project Size: Plot Area of 2 Acres & Floor Area of 90,000Sqft. Client Name: Military Engineer Service, Chief Engineer Kolkata Zone. Profile: Principal Architect with Hospital Design & Planning, Structure & Services incl MGPS System, worked on Conceptual Design & Planning based on Line Diagram & Approval from All Departments & and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010.
Project Size: Plot Area of 10 Acres & Floor Area of 70,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Udhampur Zone Project Cost: Rs. 21.0 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram, Admin Approval and Board Proceedings, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BIKANER AND BATHINDA, RAJASTHAN Project Size: Plot Area of 6 Acres & Floor Area of 30,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Bathinda Zone. Project Cost: Rs. 13.26 Crore (as per Admin Approval) Profile: Principal Design & Engineering Consultant, worked on Conceptual Design & Planning based all Cinematography Standards & Statutory Guidelines, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BADAMI BAGH CANTONMENT, SRINAGAR, JAMMU & KASHMIR Project Size: Plot Area of 4 Acres & Floor Area of 33,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Srinagar Zone Project Cost: approx 9.0 Crore. Consultant: Aakar Consultant & Infrastructure Developers Pvt Ltd Profile: Architecture Consultancy, Design & Planning based on Admin Approval & Board Proceeding Incorporation of client’s feedback. Preparat ion of complete Working, Detail, Services & Structural drawings. Co-ordination between Services, Structural Consultants. Schedule of Finishes, Bill of Quantity, Specification & Tender Document preparation. Specialist Design Provision of Pool Water Heating & Filtration System, Lighting of Sports Arena for Day Night Gaming Facility.
AT 407 AIR FORCE BASE, COIMBATORE, TAMILNADU Project Size: Plot Area of 4 Acres & Floor Area of 1,10,000Sqft. Client Name: Military Engineer Service, Chief Engineer Bangalore Zone Project Cost: Rs. 27.00 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram & Scale of Accommodation for Armed Force Hospital-2003, Admin Approval and Board Proceedings, Presentation & Approval from E6 Section & User (CO-6AF Hospital, Coimbatore) and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010
Complete Master Planning Work of All Building Types and Garages. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per Guidelines of Dept. Complete Architectural Work, Structural Work, Electrical & Plumbing Services work of Admin Block, Educational Building, and Officers Mess & SM Barracks and all other Bldgs. Working Drawings, Detailed Designs, SoF and BoQ for Lump-sum Tender Job as per requirement of MES.
AT BIKANER MILITARY STATION, RAJASTHAN Comprehensive Design Consultancy including Master Planning, Services Incorporation, & Co-ordination of entire land and Detailed Architecture & Engineering Consultancy for Administrative, Educational, Officers Mess, Armory Building, Officers Accommodation and multiple type S/M Barracks.
Project Size: Plot Area of 2.0 Acres & Builtup Area of 1,04,000 Sqft, 70 Nos. 2 & 3 BHK Apartments Project Cost: Rs. 14.00 Crore, Client Name: Esquire Infra Height Pvt Ltd Profile: Principal Architect involved in Design Development, All Approvals, Working, Tendering, Coordination and Supervision of the Project.
Complete Consultancy Work for 2 Storied Large Industrial Hall for repair & maintenance of INS Vikramaditya with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per SPT Method for 20M depth & foundation assessment. Complete Architectural Work, Structural Designing Work, and Electrical & Plumbing Services work of Main Hall (15 M High & Ancillary Buildings (AC Plant Room, Guard House etc).
Project Size: Institute of 360 Student & 30 Faculty, Plot Area of 5.56 Acres & Floor Area of 2,50,000 Sqft. Client Name: Indian Army (Bengal HQ), Kolkata. Profile: Principal Architect worked from conceptual design, area program, green building concept 3D view and complete design. Consultant: Aakar Consultant & Infrastructure Developers
Proposal of 70 Classes, 10 Labs with provision of future expansion of 70 Classes, 14 Labs. Complete Consultancy Work including Architectural, Structure Detailed Designs, Working Drawings, SoF, 3-D Walk-thru and BoQ for Lump-sum Tender Job. Complete Building Services Design (HVAC/Mechanical, Electrical and Plumbing & Fire Fighting), Structural Work of Admin Block, Educational Building, and Laboratory Block & Multipurpose Hall Block with adherence of clauses of NBC-2005. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user [Commandant of Bombay Sappers, Principal of School] for their input.
AT COMMAND HOSPITAL, KOLKATA Project Size: Plot Area of 2 Acres & Floor Area of 90,000Sqft. Client Name: Military Engineer Service, Chief Engineer Kolkata Zone. Profile: Principal Architect with Hospital Design & Planning, Structure & Services incl MGPS System, worked on Conceptual Design & Planning based on Line Diagram & Approval from All Departments & and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010.
Project Size: Plot Area of 10 Acres & Floor Area of 70,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Udhampur Zone Project Cost: Rs. 21.0 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram, Admin Approval and Board Proceedings, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BIKANER AND BATHINDA, RAJASTHAN Project Size: Plot Area of 6 Acres & Floor Area of 30,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Bathinda Zone. Project Cost: Rs. 13.26 Crore (as per Admin Approval) Profile: Principal Design & Engineering Consultant, worked on Conceptual Design & Planning based all Cinematography Standards & Statutory Guidelines, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BADAMI BAGH CANTONMENT, SRINAGAR, JAMMU & KASHMIR Project Size: Plot Area of 4 Acres & Floor Area of 33,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Srinagar Zone Project Cost: approx 9.0 Crore. Consultant: Aakar Consultant & Infrastructure Developers Pvt Ltd Profile: Architecture Consultancy, Design & Planning based on Admin Approval & Board Proceeding Incorporation of client’s feedback. Preparat ion of complete Working, Detail, Services & Structural drawings. Co-ordination between Services, Structural Consultants. Schedule of Finishes, Bill of Quantity, Specification & Tender Document preparation. Specialist Design Provision of Pool Water Heating & Filtration System, Lighting of Sports Arena for Day Night Gaming Facility.
AT 407 AIR FORCE BASE, COIMBATORE, TAMILNADU Project Size: Plot Area of 4 Acres & Floor Area of 1,10,000Sqft. Client Name: Military Engineer Service, Chief Engineer Bangalore Zone Project Cost: Rs. 27.00 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram & Scale of Accommodation for Armed Force Hospital-2003, Admin Approval and Board Proceedings, Presentation & Approval from E6 Section & User (CO-6AF Hospital, Coimbatore) and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010
Complete Master Planning Work of All Building Types and Garages. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per Guidelines of Dept. Complete Architectural Work, Structural Work, Electrical & Plumbing Services work of Admin Block, Educational Building, and Officers Mess & SM Barracks and all other Bldgs. Working Drawings, Detailed Designs, SoF and BoQ for Lump-sum Tender Job as per requirement of MES.
AT BIKANER MILITARY STATION, RAJASTHAN Comprehensive Design Consultancy including Master Planning, Services Incorporation, & Co-ordination of entire land and Detailed Architecture & Engineering Consultancy for Administrative, Educational, Officers Mess, Armory Building, Officers Accommodation and multiple type S/M Barracks.
Project Size: Plot Area of 2.0 Acres & Builtup Area of 1,04,000 Sqft, 70 Nos. 2 & 3 BHK Apartments Project Cost: Rs. 14.00 Crore, Client Name: Esquire Infra Height Pvt Ltd Profile: Principal Architect involved in Design Development, All Approvals, Working, Tendering, Coordination and Supervision of the Project.
Complete Consultancy Work for 2 Storied Large Industrial Hall for repair & maintenance of INS Vikramaditya with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per SPT Method for 20M depth & foundation assessment. Complete Architectural Work, Structural Designing Work, and Electrical & Plumbing Services work of Main Hall (15 M High & Ancillary Buildings (AC Plant Room, Guard House etc).
Project Size: Institute of 360 Student & 30 Faculty, Plot Area of 5.56 Acres & Floor Area of 2,50,000 Sqft. Client Name: Indian Army (Bengal HQ), Kolkata. Profile: Principal Architect worked from conceptual design, area program, green building concept 3D view and complete design. Consultant: Aakar Consultant & Infrastructure Developers
Proposal of 70 Classes, 10 Labs with provision of future expansion of 70 Classes, 14 Labs. Complete Consultancy Work including Architectural, Structure Detailed Designs, Working Drawings, SoF, 3-D Walk-thru and BoQ for Lump-sum Tender Job. Complete Building Services Design (HVAC/Mechanical, Electrical and Plumbing & Fire Fighting), Structural Work of Admin Block, Educational Building, and Laboratory Block & Multipurpose Hall Block with adherence of clauses of NBC-2005. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user [Commandant of Bombay Sappers, Principal of School] for their input.
AT COMMAND HOSPITAL, KOLKATA Project Size: Plot Area of 2 Acres & Floor Area of 90,000Sqft. Client Name: Military Engineer Service, Chief Engineer Kolkata Zone. Profile: Principal Architect with Hospital Design & Planning, Structure & Services incl MGPS System, worked on Conceptual Design & Planning based on Line Diagram & Approval from All Departments & and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010.
Project Size: Plot Area of 10 Acres & Floor Area of 70,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Udhampur Zone Project Cost: Rs. 21.0 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram, Admin Approval and Board Proceedings, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BIKANER AND BATHINDA, RAJASTHAN Project Size: Plot Area of 6 Acres & Floor Area of 30,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Bathinda Zone. Project Cost: Rs. 13.26 Crore (as per Admin Approval) Profile: Principal Design & Engineering Consultant, worked on Conceptual Design & Planning based all Cinematography Standards & Statutory Guidelines, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BADAMI BAGH CANTONMENT, SRINAGAR, JAMMU & KASHMIR Project Size: Plot Area of 4 Acres & Floor Area of 33,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Srinagar Zone Project Cost: approx 9.0 Crore. Consultant: Aakar Consultant & Infrastructure Developers Pvt Ltd Profile: Architecture Consultancy, Design & Planning based on Admin Approval & Board Proceeding Incorporation of client’s feedback. Preparat ion of complete Working, Detail, Services & Structural drawings. Co-ordination between Services, Structural Consultants. Schedule of Finishes, Bill of Quantity, Specification & Tender Document preparation. Specialist Design Provision of Pool Water Heating & Filtration System, Lighting of Sports Arena for Day Night Gaming Facility.
AT 407 AIR FORCE BASE, COIMBATORE, TAMILNADU Project Size: Plot Area of 4 Acres & Floor Area of 1,10,000Sqft. Client Name: Military Engineer Service, Chief Engineer Bangalore Zone Project Cost: Rs. 27.00 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram & Scale of Accommodation for Armed Force Hospital-2003, Admin Approval and Board Proceedings, Presentation & Approval from E6 Section & User (CO-6AF Hospital, Coimbatore) and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010
Complete Master Planning Work of All Building Types and Garages. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per Guidelines of Dept. Complete Architectural Work, Structural Work, Electrical & Plumbing Services work of Admin Block, Educational Building, and Officers Mess & SM Barracks and all other Bldgs. Working Drawings, Detailed Designs, SoF and BoQ for Lump-sum Tender Job as per requirement of MES.
AT BIKANER MILITARY STATION, RAJASTHAN Comprehensive Design Consultancy including Master Planning, Services Incorporation, & Co-ordination of entire land and Detailed Architecture & Engineering Consultancy for Administrative, Educational, Officers Mess, Armory Building, Officers Accommodation and multiple type S/M Barracks.
Project Size: Plot Area of 2.0 Acres & Builtup Area of 1,04,000 Sqft, 70 Nos. 2 & 3 BHK Apartments Project Cost: Rs. 14.00 Crore, Client Name: Esquire Infra Height Pvt Ltd Profile: Principal Architect involved in Design Development, All Approvals, Working, Tendering, Coordination and Supervision of the Project.
Complete Consultancy Work for 2 Storied Large Industrial Hall for repair & maintenance of INS Vikramaditya with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per SPT Method for 20M depth & foundation assessment. Complete Architectural Work, Structural Designing Work, and Electrical & Plumbing Services work of Main Hall (15 M High & Ancillary Buildings (AC Plant Room, Guard House etc).
Project Size: Institute of 360 Student & 30 Faculty, Plot Area of 5.56 Acres & Floor Area of 2,50,000 Sqft. Client Name: Indian Army (Bengal HQ), Kolkata. Profile: Principal Architect worked from conceptual design, area program, green building concept 3D view and complete design. Consultant: Aakar Consultant & Infrastructure Developers
Proposal of 70 Classes, 10 Labs with provision of future expansion of 70 Classes, 14 Labs. Complete Consultancy Work including Architectural, Structure Detailed Designs, Working Drawings, SoF, 3-D Walk-thru and BoQ for Lump-sum Tender Job. Complete Building Services Design (HVAC/Mechanical, Electrical and Plumbing & Fire Fighting), Structural Work of Admin Block, Educational Building, and Laboratory Block & Multipurpose Hall Block with adherence of clauses of NBC-2005. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user [Commandant of Bombay Sappers, Principal of School] for their input.
AT COMMAND HOSPITAL, KOLKATA Project Size: Plot Area of 2 Acres & Floor Area of 90,000Sqft. Client Name: Military Engineer Service, Chief Engineer Kolkata Zone. Profile: Principal Architect with Hospital Design & Planning, Structure & Services incl MGPS System, worked on Conceptual Design & Planning based on Line Diagram & Approval from All Departments & and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010.
Project Size: Plot Area of 10 Acres & Floor Area of 70,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Udhampur Zone Project Cost: Rs. 21.0 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram, Admin Approval and Board Proceedings, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BIKANER AND BATHINDA, RAJASTHAN Project Size: Plot Area of 6 Acres & Floor Area of 30,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Bathinda Zone. Project Cost: Rs. 13.26 Crore (as per Admin Approval) Profile: Principal Design & Engineering Consultant, worked on Conceptual Design & Planning based all Cinematography Standards & Statutory Guidelines, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BADAMI BAGH CANTONMENT, SRINAGAR, JAMMU & KASHMIR Project Size: Plot Area of 4 Acres & Floor Area of 33,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Srinagar Zone Project Cost: approx 9.0 Crore. Consultant: Aakar Consultant & Infrastructure Developers Pvt Ltd Profile: Architecture Consultancy, Design & Planning based on Admin Approval & Board Proceeding Incorporation of client’s feedback. Preparat ion of complete Working, Detail, Services & Structural drawings. Co-ordination between Services, Structural Consultants. Schedule of Finishes, Bill of Quantity, Specification & Tender Document preparation. Specialist Design Provision of Pool Water Heating & Filtration System, Lighting of Sports Arena for Day Night Gaming Facility.
AT 407 AIR FORCE BASE, COIMBATORE, TAMILNADU Project Size: Plot Area of 4 Acres & Floor Area of 1,10,000Sqft. Client Name: Military Engineer Service, Chief Engineer Bangalore Zone Project Cost: Rs. 27.00 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram & Scale of Accommodation for Armed Force Hospital-2003, Admin Approval and Board Proceedings, Presentation & Approval from E6 Section & User (CO-6AF Hospital, Coimbatore) and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010
Complete Master Planning Work of All Building Types and Garages. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per Guidelines of Dept. Complete Architectural Work, Structural Work, Electrical & Plumbing Services work of Admin Block, Educational Building, and Officers Mess & SM Barracks and all other Bldgs. Working Drawings, Detailed Designs, SoF and BoQ for Lump-sum Tender Job as per requirement of MES.
AT BIKANER MILITARY STATION, RAJASTHAN Comprehensive Design Consultancy including Master Planning, Services Incorporation, & Co-ordination of entire land and Detailed Architecture & Engineering Consultancy for Administrative, Educational, Officers Mess, Armory Building, Officers Accommodation and multiple type S/M Barracks.
Project Size: Plot Area of 2.0 Acres & Builtup Area of 1,04,000 Sqft, 70 Nos. 2 & 3 BHK Apartments Project Cost: Rs. 14.00 Crore, Client Name: Esquire Infra Height Pvt Ltd Profile: Principal Architect involved in Design Development, All Approvals, Working, Tendering, Coordination and Supervision of the Project.
Complete Consultancy Work for 2 Storied Large Industrial Hall for repair & maintenance of INS Vikramaditya with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user. Soil Investigation as per SPT Method for 20M depth & foundation assessment. Complete Architectural Work, Structural Designing Work, and Electrical & Plumbing Services work of Main Hall (15 M High & Ancillary Buildings (AC Plant Room, Guard House etc).
Project Size: Institute of 360 Student & 30 Faculty, Plot Area of 5.56 Acres & Floor Area of 2,50,000 Sqft. Client Name: Indian Army (Bengal HQ), Kolkata. Profile: Principal Architect worked from conceptual design, area program, green building concept 3D view and complete design. Consultant: Aakar Consultant & Infrastructure Developers
Proposal of 70 Classes, 10 Labs with provision of future expansion of 70 Classes, 14 Labs. Complete Consultancy Work including Architectural, Structure Detailed Designs, Working Drawings, SoF, 3-D Walk-thru and BoQ for Lump-sum Tender Job. Complete Building Services Design (HVAC/Mechanical, Electrical and Plumbing & Fire Fighting), Structural Work of Admin Block, Educational Building, and Laboratory Block & Multipurpose Hall Block with adherence of clauses of NBC-2005. Presentation and Design in accordance with Board Proceeding, Admin Approval with Guidelines from MES and in discussion with user [Commandant of Bombay Sappers, Principal of School] for their input.
AT COMMAND HOSPITAL, KOLKATA Project Size: Plot Area of 2 Acres & Floor Area of 90,000Sqft. Client Name: Military Engineer Service, Chief Engineer Kolkata Zone. Profile: Principal Architect with Hospital Design & Planning, Structure & Services incl MGPS System, worked on Conceptual Design & Planning based on Line Diagram & Approval from All Departments & and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants and various MES Section. Preparation of Schedule of Finishes based on MES SSR – 2009, SSR 2010.
Project Size: Plot Area of 10 Acres & Floor Area of 70,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Udhampur Zone Project Cost: Rs. 21.0 Crore Profile: Hospital Design Architect worked on Conceptual Design & Planning based on Line Diagram, Admin Approval and Board Proceedings, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
AT BIKANER AND BATHINDA, RAJASTHAN Project Size: Plot Area of 6 Acres & Floor Area of 30,000 Sqft. Client Name: Military Engineer Service, Chief Engineer Bathinda Zone. Project Cost: Rs. 13.26 Crore (as per Admin Approval) Profile: Principal Design & Engineering Consultant, worked on Conceptual Design & Planning based all Cinematography Standards & Statutory Guidelines, Approval from E6 Section & User and incorporation of their feedback. Preparation of complete Working, Detail, Services Drawings. Co-ordination between Services, Structural Consultants. Preparation of Schedule of Finishes, Bill of Quantity, Specification. Support & Coordination with Client & Executing GE with additional detail during Construction of the Project.
ARCHITECTURE
ENGINEERING
INTERIOR DESIGN
URBAN PLANNING
HOSPITAL ARCHITECTURE & PLANNING
ARCHITECTURE APPROVAL & LIASIONING
AUDITORIUM ARCHITECTURE AND DESIGN
We are a young energetic team (established in early 2000s), doing quality work in
the field of Infrastructural Development. We produce state-of-the-art products varying
from Housing, Commercial, Institutional, IT/ITES & Hospital buildings.
We are Team of 12-15 Well Qualified Engineers & Architects dedicatedly looking
after quality and timely delivery. We differentiate ourselves from the industry by
delivering innovative concepts and better detailing.
A Consortium of Techies, Expertise in Different Aspects of Infrastructural Development. Our involvement varies from designing, Engineering, Execution & Co- Ordination with Clients, Consultants, Vendors & Competent Authorities.
Our Advanced project management system provides Value added services for high standard buildings. We manage the projects keeping in mind all Technical, Feasible, Legal, Aesthetic & Service Aspects.
We design as per available site conditions, by using maximum of permissible building controls i.e. FAR, Ground Coverage, Height Limitations, Earthquake Resistant Structural Systems and Fire Safety Norms.
We believe in early planning and timely completion. Proper coordination of Architects, Consultants & Contractors, time-to-time site visits enables us to finish a project within the expected time-frame.
A Team of Dedicated Individuals Work Together for a Project, ensuring a Satisfactory and Fruitful Result for the Client.
